iKOOLCORE

R2 NUC - Palm-sized mini PC - EOL

$239.00 USD
$239.00 USD
Sale Sold out
Shipping calculated at checkout.
Processor
Memory(Onboard, non-upgradable, LPDDR5)
Solid-state Disk(M.2 2242 NVMe/SATA, Upgradable)

Notify me when it's back in stock

This option is currently sold out. Enter your email and we'll let you know as soon as it's available again.

 View full details

Processor

  • Available with Intel N95 or Intel Core i3-N300

Memory

  • Integrated LPDDR5 4800MHz; configurable with 8GB or 16GB

Ethernet

  • 1 × Intel i226-V 2.5GbE network port (PCIe interface)

Storage

  • Supports NVMe or SATA (NGFF) M.2 2242 SSDs, up to 2TB

USB Ports

  • 4 × USB-A 3.2 Gen 1 (5Gbps)
  • 1 × USB-C 3.2 Gen 2 (10Gbps)

Display Output

  • Dual HDMI 2.0 and one USB-C video output; supports 4K @ 60Hz

Wireless Connectivity

  • E-Key socket supports optional Wi-Fi 6/6E + Bluetooth modules (not included)

Audio

  • USB-C audio port powered by Realtek ALC897

Cooling System

  • All-copper CPU heatsink with PWM fan
  • CNC-machined aluminum top for passive M.2 SSD cooling

OS Compatibility

  • Fully compatible with Windows, Linux, pfSense, OPNsense, OpenWrt, Proxmox VE, VMware ESXi, Unraid, and more

BIOS

  • AMI EFI BIOS with support for auto power-on, Wake-on-LAN (WOL), and PXE boot

Power Supply

  • 12V/4000mA DC adapter included
  • Regional plug provided
  • Supports PD protocol with GaN power adapters

Dimensions

  • 7.5 × 7.5 × 5.2 cm (2.96 × 2.96 × 2.05 inches)

Weight

  • 420g (device only)
  • 850g (with packaging)
